Alle SainSmart Kameras für Raspberry Pi:
|
Modell |
Support |
Auflösung |
Sensor |
Einstellbare Schärfe |
IR |
Licht unterstützung |
Ankel (Grad) |
Größe (mm) |
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
× |
× |
× |
73 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
× |
√ |
√ |
73 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
√ |
√ |
76 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
× |
√ |
160 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
√ |
√ |
160 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
× |
√ |
175 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
√ |
√ |
175 |
25x24 |
|
|
Raspberry Pi/ Pi2 /Pi3 Model A/ B/ B+ |
5MP |
OV5647 |
√ |
√ |
√ |
76 |
31x32 |
|
|
Raspberry Pi Zero , Pi Zero w |
5MP |
OV5647 |
× |
× |
× |
73 |
60x8 |
|
|
Raspberry Pi Zero , Pi Zero w |
5MP |
OV5647 |
× |
√ |
× |
73 |
60x8 |
Technische Daten
| Lens | 1/4 inch |
| Pixel | 5 Mega |
| Ssensor | OV5647 |
| Auflösung | 2952 × 1944 |
| Aperture | 2.9 |
| Focal Länge | 3.29 |
| FOV | 72.4 degrees |
| Kabel Länge | 2.36 inch / 60 mm |
| Video | Supports 1080p@30fps, 720p@60fps and 640x480p 60/90 Recording |
| Kompetibel | Free driver, Raspberry Pi Zero |
| Größe | 2.36 x 0.45 x 0.2 inch (60 x 11.5 x 5 mm ) |
Lieferumfang
1x Mini 5MP Raspberry Pi Zero Kamera Modul
